Description
Features
Tractor frame: welded, heavy-duty 1.5″ x 2.5″ tubular steel.
Steering control: twin levers with center fixed reference bar for ease of control forward and reverse
Front caster tires: 13 x 5.0-6, smooth-tread, semipneumatic tires with tapered roller bearings.
Drive tires: 20×10.0-8
Float guage fuel indicator
Lever-actuated bar brake.
No maintenance, sealed and nongreasable spindles; 7.75″ diameter cutter housing with 1.75″ diameter splined blade driver 1.0″-diameter spindle shaft
Electrical: 12-volt battery with 20-amp alternator.
Casters: .50 thick caster yoke arms with tapered roller bearings
Engine hour meter
Full floating ultracut series 4 side discharge deck 52″
Specifications
Engine: Kohler ECV740
Engine speed: 3,750 rpm
Engine displacement: 747
Speed: infinitely variable speed selection 0?8.5 mph (13.68 kmph) forward
Cutting heights: 1.5″ (3.8 cm) to 5.0″ (12.7 cm) in 0.25″ (0.64 cm) increments
3 blades at 18.00″ length
Blade tip speed: approximately 18,500 fpm.
Width: 64.79″
Length: 65.33″
Height: 49.2″
Curb weight: 978 lbs
