Description
- Tractor frame: welded, heavy-duty 1.5″ x 2.5″ tubular steel.
- Steering control: twin levers with center fixed reference bar for ease of control forward and reverse
- Front caster tires: 13 x 5.0-6, smooth-tread, semipneumatic tires with tapered roller bearings.
- Drive tires: 20×10.0-8
- Float guage fuel indicator
- Lever-actuated bar brake.
- No maintenance, sealed and nongreasable spindles; 7.75″ diameter cutter housing with 1.75″ diameter splined blade driver 1.0″-diameter spindle shaft
- Electrical: 12-volt battery with 15-amp alternator.
- Casters: .50 thick caster yoke arms with tapered roller bearings
- Engine hour meter
- Full floating ultracut series 4 side discharge deck 60″
- Engine: Kohler ECV740
- Engine speed: 3,750 rpm
- Engine displacement: 747
- Speed: infinitely variable speed selection 0-8.5 mph (13.68 kmph) forward
- Cutting heights: 1.5″ (3.8 cm) to 5.0″ (12.7 cm) in 0.50″ (1.27 cm) increments
- 3 blades at 20.50″ length
- Blade tip speed: approximately 18,500 fpm.
- Width: 72.87″
- Length: 68.24″
- Height: 49.2″
- Curb weight: 978 lbs
